Crimp Monitors

Quality Control on Every Crimp

An endless variety of metal materials can be bent and shaped into wires, and any wire can be crimped. From automotive and aerospace to healthcare and defence, the crimping of wires is a standard manufacturing process and spans various industries. Achieving a quality crimp is critical, as even the smallest of defects can impact the reliability of the terminal and wire connections.

Monitoring the process and tracing the problem to the source, before additional costs are incurred, is the most progressive way of ensuring crimp quality assurance. Typical issues identified using in-process monitoring and crimp defect analysis include:

  • Missing wires, crimps, or strands
  • Insulation in the crimps
  • Change in crimp dimension
  • Deformed or double crimps
  • Debris caught in the terminal
  • Worn or broken tooling
  • Incorrect wire size
  • Improper placement
  • Change in crimp material
  • Variation in the crimp bell mouth

Our industry leading crimp force monitor (CFM) solutions provide accurate, effective, real-time crimp force monitoring to detect all these defects and more.

  • crimp force monitor on a wire checking machine
  • A crimp force monitor attached to a machine
  • a crimp force monitor on a manufacturing machine
  • Black crimp monitor an a wire cutting machine
  • sample of an OES crimp monitor on a wire processing machine

Browse CFM options

View some of our most popular CFM and CPM models.

Monitor Performance on All Applications

Our CFM’s are adaptable for a wide series of wire processing machines and benchtop crimping presses. They’re also configurable for a variety of crimping applications including:

  • Sequence crimping
  • Splice crimping
  • Hydraulic and pneumatic crimping presses
  • Split tool and double crimps
  • Various hardness, material density and headroom
  • Close up of hands holding yellow wires with a computer screen in the background.
  • Mature businesswoman on factory floor using digital tablet.
  • Mechanic fixing part at on the bottom of a car.
  • Man working with wires and looking through a microscope
  • Young women working in factory working with wires.

OES Crimp Force Monitors

For more than 40 years we’ve been keeping customers happy and safe by ensuring quality crimps in wire harness applications. How can we help you?
